Architectural Tubular Latch - Electro Brass & Satin Nickel - 103 case / 82.5 backset - Plain Bag of 1

£355 £591

SKU: 675673

Size: 103 case / 82.5 backset

Pack Quantity: 1 Each

Pack Type: Plain Bag

Barcode: 5.05611E+12

✅ CE Marked
Brochure Icon

Brochure Page
  • Suitable for 30 & 60 minute fire doors
  • Easily reversible by turning the live latch/bolt, suitable for both left and right hand operation
  • Fixings for electro brass & satin nickel furniture
  • Use with sprung or unsprung furniture
  • Bolt through
  • Complete with dust box and fixing screws
Minimum quantity allowed is .
Maximum quantity allowed is .
The product can only be sold in quantity increments of .

A heavy duty architectural pattern tubular latch for use in high use domestic and commercial applications. The latch features a heavy duty spring mechanism and be used with sprung and unsprung door handles.

Technical Specifications

Specification Details
Size (mm) 103 / 82.5
Backset (mm) 82.5
Faceplate Size H x W (mm) 60 x 25
Keep Size H x W (mm) 65 x 25
Lock Case Size H x D (mm) 22.5 x 103
Finish Electro Brass Satin Nickel

Features

  • Suitable for 30 & 60 minute fire doors
  • Easily reversible by turning the live latch/bolt, suitable for both left and right hand operation
  • Fixings for electro brass & satin nickel furniture
  • Use with sprung or unsprung furniture
  • Bolt through
  • Complete with dust box and fixing screws

Downloads

Description

A heavy duty architectural pattern tubular latch for use in high use domestic and commercial applications. The latch features a heavy duty spring mechanism and be used with sprung and unsprung door handles.
